Connection18
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
• In the connections shown below, some cables may not be included with
the projector (see "Shipping contents" on page 8). They are
commercially available from electronics stores.
• For detailed connection methods, see pages 19-20.
1. VGA cable 2. USB Cable
3. Component Video to VGA (DSub)
adapter cable
4. Video cable
3
4
1 2
