Introduction14
Infra-Red (IR) remote control sensor is located on the front of the projector. The
remote control must be held at an angle within 30 degrees perpendicular to the
projector's IR remote control sensor to function correctly. The distance between the
remote control and the sensor should not exceed 8 meters (~ 26 feet).
Make sure that there are no obstacles between the remote control and the IR sensor
on the projector that might obstruct the infra-red beam.
11. Power
Toggles the projector between
standby mode and on. See "Starting up
the projector" on page 21 and
"Shutting down the projector" on page
42 for details.
12. Keystone/Arrow keys ( / Up,
/Down)
Manually corrects distorted images
resulting from an angled projection. See
"Correcting keystone" on page 24 for
details.
13. Auto
Automatically determines the best
picture timings for the displayed
image. See "Auto-adjusting the image"
on page 23 for details.
14. Source
Displays the source selection bar. See
"Switching input signal" on page 29 for
details.
15. Volume +/-
No function for this model.
16. Page Up/Down
Page up/down arrows when connected
through USB to a PC. See "Remote
paging operations" on page 37 for
details.
17. Mute
No function for this model.
18. Freeze
Freezes the projected image. See
"Freezing the image" on page 38 for
details.
19. CC
Display the video term description on
screen which is provided for hard-of-
hearing viewers.
20. Quick Install
A menu shortcut that includes Test
Pattern, Projector Installation and
Keystone.
21. Teaching Template
Displays the selectable bar for teachers
choosing the template as his/her suitable
teaching background. See "Use Teaching
Template" on page 40 for details.
22. 3D Settings
Activates the 3D On-Screen Display
(OSD) menu item.
