77
1280 x 1024 SXGA_60 60.02 63.981 108
SXGA_75 75.025 79.976 135
SXGA_85 85.024 91.146 157.5
1280 x 960 1280 x 960_60 60 60 108
1280 x 960_85 85.002 85.938 148.5
1360 x 768 1360 x 768_60 60.015 47.712 85.5
1440 x 900 WXGA+_60 59.887 55.935 106.5
1400X1050 SXGA+_60 59.978 65.317 121.75
1600x1200 UXGA 60 75 162
1680x1050 1680x1050_60 59.954 65.29 146.25
640 x 480@67Hz
(HDMI portonly)
MAC13 66.667 35 30.24
832 x 624@75Hz
(HDMI portonly)
MAC16 74.546 49.722 57.28
1024 x 768@75 Hz MAC19 75.02 60.241 80
1152 x 870@75 Hz MAC21 75.02 68.68 100
1920 x 1080 @60HZ 1920X1080_60
(CEA-861)
60 67.5 148.5
The timings showing above may not be supported for due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen.
Resolution Mode Refresh Rate (Hz) H. Frequency (KHz) Dot Clock Frequency (MHz)
