BenQ LU9235 - Support Timing for Component - Ypbpr Input

English
71
Resolution Mode
Refresh
Rate (Hz)
H
Frequency
(kHz)
Clock
(MHz)
3D Frame
Sequential
3D Top
Bottom
3D side-
by-side
1440 x 900 WXGA+_60 59.887 55.935 106.500
◎ ◎
1400 x 1050 SXGA+_60 59.978 65.317 121.750
◎ ◎
1600 x 1200 UXGA 60.000 75.000 162.000
◎ ◎
1680 x 1050 1680 x 1050_60 59.954 65.290 146.250
◎ ◎
*1920 x 1080
@60Hz
1920 x 1080_60
(Reduce Blanking)
60.000 67.500 148.500
*1920 x 1200
@60Hz
1920 x 1200_60
(Reduce Blanking)
59.950 74.038 154.000
640 x 480
@67Hz
MAC13 66.667 35.000 30.240
832 x 624
@75Hz
MAC16 74.546 49.722 57.28 0
1024 x 768
@75Hz
MAC19 74.930 60.241 80.000
1152 x 870
@75Hz
MAC21 75.060 68.68 100.000
Note:
There 3D timing showing depend the EDID le and VGA display card. It is possible that user cannot choose the above
3D timings on VGA display card.
*: No available in PC 2.
Support timing for Component - YPbPr input
Timing Resolution
Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
Dot Clock
Frequency (MHz)
3D Frame
Sequential
480i 720 x 480 15.73 59.94 13.50
◎
480p 720 x 480 31.47 59.94 27.00
◎
576i 720 x 576 15.63 50.00 13.50
576p 720 x 576 31.25 50.00 27.0 0
720/50p 1280 x 720 37. 50 50.00 74.25
720/60p 1280 x 720 45.00 60.00 74.25
◎
1080/50i 1920 x 1080 28.13 50.00 74.25
1080/60i 1920 x 1080 33.75 60.00 74.25
1080/24p 1920 x 1080 27.0 0 24.00 74.25
1080/25p 1920 x 1080 28.13 25.00 74.25
1080/30p 1920 x 1080 33.75 30.00 74.25
1080/50p 1920 x 1080 56.25 50.00 148.50
1080/60p 1920 x 1080 67.50 60.00 148.50
