Support timing for Video input
Video Mode
Horizontal
Frequency (KHz)
Vertical
Frequency (Hz)
Sub-carrier
Frequency (MHz)
3D Frame
Sequential
NTSC 15.73 60 3.58
◎
PAL 15.63 50 4.43
SECAM 15.63 50 4.25 or 4.41
PAL-M 15.73 60 3.58
PAL-N 15.63 50 3.58
PAL-60 15.73 60 4.43
NTSC4.43 15.73 60 4.43
Support timing for HDMI & DVI-D (HDCP) input
Resolution Mode
Refresh
Rate (Hz)
H
Frequency
(kHz)
Clock
(MHz)
3D Frame
Sequential
3D Top
Bottom
3D side-
by-side
640 x 480
VGA_60 59.940 31.469 25.175
◎ ◎ ◎
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
720 x 400 720 x 400_70 70.087 31.469 28.3221
800 x 600
SVGA_60 60.317 37.879 40.000
◎ ◎ ◎
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
SVGA _120
(Reduce Blanking)
119. 8 5 4 77.425 83.000
◎
1024 x 768
XGA_60 60.004 48.363 65.000
◎ ◎ ◎
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
XGA_120
(Reduce Blanking)
119.9 8 9 97.551 115.500
◎
1152 x 864 1152 x 864_75 75.000 67.500 108.000
1024 x 576
BenQ Notebook
Timing
60.000 35.820 46.996
1024 x 600
BenQ Notebook
Timing
64.995 41.467 51.419
1280 x 720 1280 x 720_60 60.000 45.000 74.250
◎ ◎ ◎
1280 x 768 1280 x 768_60 59.870 47.776 79.5
◎ ◎ ◎
