Resolution Mode
Refresh
Rate (Hz)
H
Frequency
(kHz)
Clock
(MHz)
3D Frame
Sequential
3D Top
Bottom
3D side-
by-side
1280 x 800
WXGA_60 59.810 49.702 83.500
◎ ◎ ◎
WXGA_75 74.934 62.795 106.500
WXGA_85 84.880 71.554 122.500
WXGA_120
(Reduce Blanking)
119.9 09 101.563 146.250
◎
1280 x 1024
SXGA_60 60.020 63.981 108.000
◎ ◎
SXGA_75 75.025 79.976 135.000
SXGA_85 85.024 91.146 157.500
1280 x 960
1280 x 960_60 60.000 60.000 108.000
◎ ◎
1280 x 960_85 85.002 85.938 148.500
1360 x 768 1360 x 768_60 60.015 47.712 85.500
◎ ◎
1440 x 900 WXGA+_60 59.887 55.935 106.500
◎ ◎
1400 x 1050 SXGA+_60 59.978 65.317 121.750
◎ ◎
1600 x 1200 UXGA 60.000 75.000 162.000
◎
1680 x 1050 1680 x 1050_60 59.954 65.290 146.250
◎ ◎
1920 x 1080
@60Hz
1920 x 1080_60
(Reduce Blanking)
60.000 67.500 148.500
1920 x 1200
@60Hz
1920 x 1200_60
(Reduce Blanking)
59.950 74.038 154.000
640 x 480
@67Hz
MAC13 66.667 35.000 30.240
832 x 624
@75Hz
MAC16 74.546 49.722 57.28 0
1024 x 768
@75Hz
MAC19 75.020 60.241 80.000
1152 x 870
@75Hz
MAC21 75.060 68.680 100.000
Note:
There timing showing depend the EDID le and VGA graphic card limitation. It is possible that user cannot choose the
above timings on VGA display card.
