9 Introduction
Controls and functions
Projector & Remote control
1. POWER
Toggles the projector between standby mode
and on.
ON/ OFF
Turns on or off the projector.
2. POWER indicator light/TEMPerature
warning light/LIGHT indicator light
(See Indicators on page 42.)
3. SOURCE
Displays the source selection bar.
4. BACK
Goes back to previous OSD menu.
Exits and saves menu settings when it is on the
top level of OSD menu.
5. Arrow keys ( , , , )
When the On-Screen Display (OSD) menu is
activated, these keys are used as directional
arrows to select the desired menu items and
to make adjustments.
Keystone keys ( , )
Displays the keystone correction page.
Volume keys /
Decreases or increase the projector volume.
6. ECO BLANK
Press this button to turn off the image for a
period of time with 70% lamp power saving.
Press again to restore the image.
Do not block the projection lens from
projecting as this could cause the blocking
object to become heated and deformed or
even cause a fire.
All the key presses described in this document
are available on the remote control or projector.
3
4
5
7
6
8
2
1
9
1
3
4
5
6
7
9
8
11
12
13
14
16
17
18
20
21
19
15
10
