15 Positioning your projector
MW864UST
• The screen aspect ratio is 16:10 and the projected picture is in a 16:10 aspect ratio
Mounting the projector
If you intend to mount your projector, we strongly recommend that you use a proper fitting BenQ
projector mounting kit and that you ensure it is securely and safely installed.
If you use a non-BenQ brand projector mounting kit, there is a safety risk that the projector may fall
down due to an improper attachment through the use of the wrong gauge or length screws.
Before mounting the projector
• Purchase a BenQ projector mounting kit from the place you purchased your BenQ projector.
• BenQ recommends that you also purchase a separate Kensington lock compatible security cable and
attach it securely to both the Kensington lock slot on the projector and the base of the mounting
bracket. This will perform the secondary role of restraining the projector should its attachment to the
mounting bracket become loose.
• Ask your dealer to install the projector for you. Installing the projector on your own may cause it to
fall and result in injury.
• Take necessary procedures to prevent the projector from falling off such as during an earthquake.
• The warranty doesn’t cover any product damage caused by mounting the projector with a non-BenQ
brand projector mounting kit.
• Consider the surrounding temperature where the projector is ceiling/wall mounted. If a heater is used,
the temperature around the ceiling may be higher than expected.
Screen size
Minimum
Ceiling height
Ver tical
offset
Installation distance (D)
Diagonal (M) Height (h) Width (W)
H
a
a. Based on an image 762 mm from the floor, if the image is lower, the min ceiling height is reduced by the measurement.
V
X
b
=0 mm
(D=a)
b. Assume the thickness of projection screen(X) is 0 mm.
X
c
=30 mm
(D=a+30 mm)
c. Assume the thickness of projection screen(X) is 30 mm.
Inch mm (mm) (mm) (mm) (mm) (mm) (mm)
86.5 2197 1164 1863 2430 216 88 118
87 2210 1171 1874 2438 217 91 121
90 2286 1212 1939 2485 223 106 136
95 2413 1279 2046 2562 233 131 161
100 2540 1346 2154 2639 243 156 186
105 2667 1414 2262 2717 253 181 211
110 2794 1481 2369 2794 263 206 236
115 2921 1548 2477 2872 273 231 261
120 3048 1615 2585 2949 284 256 286
125 3175 1683 2692 3026 294 281 311
130 3302 1750 2800 3104 304 306 336
All measurements are approximate and may vary from the actual sizes.
BenQ recommends that if you intend to permanently install the projector, you should physically test the projection
size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this
projector's optical characteristics. This will help you determine the exact mounting position so that it best suits your
installation location.
