26 Menu operation
Menu operation
Please note that the on-screen display (OSD) menus vary according to the signal type selected and the
projector model you are using.
The menu items are available when the projector detects at least one valid signal. If there is no
equipment connected to the projector or no signal detected, limited menu items are accessible.
DISPLAY menu
Wall Color
Corrects the projected picture’s color when the projection surface such as a
painted wall which may not be white, the Wall Color feature can help correct the
projected picture’s colors to prevent possible color difference between the source
and projected pictures. There are several precalibrated colors to choose from:
Light Yellow, Pink, Light Green, Blue, and Blackboard.
Aspect Ratio
There are several options to set the image's aspect ratio depending on your input
signal source.
• Auto: Scales an image proportionally to fit
the projector's native resolution in its
horizontal or vertical width.
• Real: Projects an image as its original
resolution and resizes it to fit within the
display area. For input signals with lower
resolutions, the projected image will display
smaller than if resized to full screen.
• 4:3: Scales an image so that it is displayed in
the center of the screen with a 4:3 aspect
ratio.
• 16:9: Scales an image so that it is displayed in
the center of the screen with a 16:9 aspect
ratio.
• 16:10: Scales an image so that it is displayed
in the center of the screen with a 16:10
aspect ratio.
2D Keystone Corrects any keystoning of the image. See Correcting keystone on page 17.
Corner Fit Adjusts four corners of the image. See Adjusting Corner Fit on page 17.
Position
Displays the position adjustment page. To move the projected image, use the
directional arrow keys. This function is only available when a PC signal (analog RGB)
is selected.
Phase
Adjusts the clock phase to reduce image distortion. This
function is only available when a PC signal (analog RGB)
is selected.
