47 Specifications
• Video timings
Supported timing for MHL input
Supported timing for Component-YPbPr input
Timing Resolution
Ver tic a l
Frequency (Hz)
Horizontal Frequency
(kHz)
Pixel Frequency
(MHz)
480i* 720 x 480 59.94 15.73 27
480p* 720 x 480 59.94 31.47 27
576i 720 x 576 50 15.63 27
576p 720 x 576 50 31.25 27
720/50p** 1280 x 720 50 37.5 74.25
720/60p*** 1280 x 720 60 45.00 74.25
1080/50i**** 1920 x 1080 50 28.13 74.25
1080/60i**** 1920 x 1080 60 33.75 74.25
1080/24P** 1920 x 1080 24 27 74.25
1080/25P 1920 x 1080 25 28.13 74.25
1080/30P 1920 x 1080 30 33.75 74.25
1080/50P***** 1920 x 1080 50 56.25 148.5
1080/60P***** 1920 x 1080 60 67.5 148.5
• *Supported timing for 3D signal in Frame Sequential format.
• **Supported timing for 3D signal in Top Bottom, Frame Packing and Side by Side formats.
• ***Supported timing for 3D signal in Frame Sequential, Top Bottom, Frame Packing and Side by Side
formats.
• ****Supported timing for 3D signal in Side by Side format.
• *****Supported timing for 3D signal in Top Bottom and Side by Side formats.
Timing Resolution
Vertical Frequency
(Hz)
Horizontal
Frequency (kHz)
Pixel Frequency
(MHz)
480i 720 (1440) x 480 59.94 15.73 27
480p 720 x 480 59.94 31.47 27
576i 720 (1440) x 576 50 15.63 27
576p 720 x 576 50 31.25 27
720/50p 1280 x 720 50 37.5 74.25
720/60p 1280 x 720 60 45.00 74.25
1080/24P 1920 x 1080 24 27 74.25
1080/25P 1920 x 1080 25 28.13 74.25
1080/30P 1920 x 1080 30 33.75 74.25
1080/50i 1920 x 1080 50 28.13 74.25
1080/60i 1920 x 1080 60 33.75 74.25
1080/50p 1920 x 1080 50 56.25 148.5
1080/60p 1920 x 1080 60 67.5 148.5
Timing Resolution
Vertical Frequency
(Hz)
Horizontal Frequency
(kHz)
Pixel Frequency
(MHz)
480i* 720 x 480 59.94 15.73 13.5
480p* 720 x 480 59.94 31.47 27
576i 720 x 576 50 15.63 13.5
576p 720 x 576 50 31.25 27
720/50p 1280 x 720 50 37.5 74.25
720/60p* 1280 x 720 60 45.00 74.25
1080/50i 1920 x 1080 50 28.13 74.25
1080/60i 1920 x 1080 60 33.75 74.25
1080/24P 1920 x 1080 24 27 74.25
1080/25P 1920 x 1080 25 28.13 74.25
1080/30P 1920 x 1080 30 33.75 74.25
1080/50P 1920 x 1080 50 56.25 148.5
1080/60P 1920 x 1080 60 67.5 148.5
