Product information 58
ST7502S
Unit: mm
52.3mm
COVER THICKNESS=0.81mm
348
4
20
4
1.8
348
20
4
4

1
.
8
15.5mm
82.9mm
69.5mm
400
20
4
4
Bezel Width=14.9mm(T/R/L/B)
1683.46mm
961.74mm

1
.
8
AC
WALL MOUNT SCREW=M8*(15+X) (X=WALL MOUNT BKT THICKNESS)
280.87mm
400mm
745.23mm
100mm 100mm
51.37mm
100mm
600mm
541.73mm
541.73mm

1.
9
4
176
4
104
104
84
4
4
72
4
4
72
2
.
8

2
.
8
IO-Side
IO-Bottom
95.3mm
HDMI3 IN USB2.0
USB2.0
MICRO SD
RS232
OUT
RS232
IN
IR-IN
IR-OUT
HDMI1 IN
HDMI2 IN
AUDIO OUT
DVI-D IN
RJ45
PC LINE IN
VGA IN
Q40G1001-813-79A
Q40G1001-813-80A
HDMI3 IN
USB2.0
USB2.0
MICRO SD
RS232
IR-IN
IR-OUT
IN
RS232
OUT
HDMI1 IN
HDMI2 IN
AUDIO OUT
DVI-D IN
RJ45
PC LINE IN
VGA IN
