INTRODUCTION
The Absoluta control panel series consists of the mod
-
els listed in Table 1.
The Absoluta series is based on the Absoluta 630,
Absoluta Plus 18, Absoluta Plus 48, Absoluta Plus 128,
and Absoluta Plus 128 G3 platforms: the platforms de
-
termine the general features of the models, as indicated
in Table 2; the models of the same platform differ only in
the box and the power supply.
This manual is designed for anyone using a control panel
from the Absoluta range. Most of the features described
in this manual are included on all Absoluta control pan
-
els. However, some features are included on certain
models only, in such cases, the name of the control
panel will be specified.
3
This note will be used to highlight specific charac
-
teristics of the Grade 3 control panels (Table 1).
Absoluta Plus and Absoluta 630 INTRODUCTION 5
Platforms Models Main Boards Boxes Power Supplies
Absoluta 630 ABS630P35 ABS-630 BOX-PLUS BAW35T12
Absoluta Plus 18 ABS18P15
*
ABS-18 ABS-P BAQ15T12
Absoluta Plus 18 ABS18P35
*
ABS-18 ABS-P BAW35T12
Absoluta Plus 48 ABS48P35
*
ABS-48 ABS-P BAW35T12
Absoluta Plus 48 ABS48P50
*
ABS-48 ABS-P BAW50T12
Absoluta Plus 128 ABS128P50* ABS-128 ABS-P BAW50T12
Absoluta Plus 18 ABS18M35 ABS-18 ABS-M BAW35T12
Absoluta Plus 48 ABS48M35
*
ABS-48 ABS-M BAW35T12
Absoluta Plus 48 ABS48M50
*
ABS-48 ABS-M BAW50T12
Absoluta Plus 48 ABS48M75
*
ABS-48 ABS-M BAW75T12
Absoluta Plus 128 ABS128M50
*
ABS-128 ABS-M BAW50T12
Absoluta Plus 128 ABS128M75
*
ABS-128 ABS-M BAW75T12
Absoluta Plus 128 G3 ABS128M75-G3
**
ABS-128G3 ABS-M BAW75T12
Table 1 *) Grade 2 control panel; **) Grade 3 control panel.
Absoluta
630
ABSOLUTA
Plus 18
ABSOLUTA
Plus 48
ABSOLUTA
Plus 128
Absoluta
Plus 128 G3
Max number of keypads 4 8 8 16 16
Number of user PINs 16 31 63 127 127
Number of keys 16 64 128 250 250
Number of Key readers 8 16323232
Max number of keyfobs 16 16 16 32 32
Number of input expansions 4 16323232
Number of output expansions 2 16161616
Number of power supply stations 04444
Max number of wired zones 30 18 48 128 128
Max number of wireless zones 30 18 48 128 128
Total max number of combined
(wired+wireless) zones
30 18 48 128 128
Number of partitions 8 8 8 16 16
Max number of output 16 16 20 50 50
Max telephone numbers 16 32 32 32 32
Table 2 Absoluta panel series features.
