List of Faults
Table 14 shows the meaning of fault messages and the
actions to take when they occur.
80 Expandable Hybrid Control Panels
MESSAGE DESCRIPTION
Zone 001(1) The detector connected to the zone with the label Zone 001
2
is faulty
(masked, etc.). Call the Installer.
PS1 low Vout (1) The output voltage of Power station No. 1 (2, 3 or 4) is less than 10.6 V. Call the Installer.
PS1 Vout1 LOW (1) The O1 (O2 or O3) output voltage of Power station No. 1 (2, 3 or 4) is less than
10.6 V. Call the Installer.
PIN to default The user PINs are NOT safe because they are the default factory ones. Change
the default PIN. If the fault System Comm. FTC is also present, the Installer PIN
must also be changed: call the installer.
Inst. access The installer has changed the programming of the control panel.
Panel bat. low The Battery voltage of the Control panel is less than 11.4 V.
Panel bat. fail The control panel battery does not pass the Dynamic test. Call the Installer.
Panel NO batt. The control panel battery is disconnected or absent. Call the Installer.
Panel bat.charg The control panel is not capable to recharge the battery. Call the Installer.
Panel NO 220v The Mains power of the Control panel has failed. Call the Installer.
Panel PSU Switching power supply does not work. Call the Installer.
Panel low Vout The output voltage of control panel is low. Call the Installer.
PS1 bat. low The battery voltage of the Power station No. 1 (2, 3 or 4) is less than 10.9 V. Call
the Installer.
PS1 bat. fail The battery of Power station No. 1 (2, 3 or 4) does not pass the Dynamic test or it is
disconnected or the Fuse -protects against Battery polarity inversion- is broken.
Call the Installer.
PS1 NO batt. Switching power supply of the Power station No. 1 (2, 3 or 4) does not work. Call
the Installer.
PS1 bat.charg The Output voltage of the Switching power supply of the Power station No. 1 (2, 3
or 4), is outside the normal range min 10.2 V max 14.7 V. Call the Installer.
PS1 NO 220v The Mains power of the Power station No. 1 (2, 3 or 4) has failed. Call the Installer.
PS1 PSU Switching power supply of the Power station No. 1 (2, 3 or 4) does not work. Call
the Installer.
PS1 low Vout The Power station No. 1 (2, 3 or 4) is not capable to supply the right output voltage.
Call the Installer.
PS1 bat. disc. The battery of the Power station No. 1 (2, 3 or 4) is disconnected when you switch
on the Power station No. 1 (2, 3 or 4). Call the Installer.
PS1 SWT disc. Switching power supply of the Power station No. 1 (2, 3 or 4) is disconnected. Call
the Installer.
PS1 Vout1 short Short circuit on Output O1 (O2 or O3) of the Power station No. 1 (2, 3 or 4). Call the
Installer.
summer time The Control panel Clock has been set/unset to Daylight savings time.
Fuse B Fuse B is opened -protects the Siren Output.
Fuse zones Zone Fuse is opened-protects the Zones power line.
Fuse BPI BPI Fuse is opened-protects the BPI line.
Fuse WlsBus Transceiver bus fuse is opened-protects the transceiver bus.
Inst. Maintenan. The date of the periodic checks of the Installer has expired.
Surve.Maintenan. The date of the periodic checks of the Central Station has expired.
Default Date The Mains power of the Control panel has failed, and the internal clock went to the
default -hour/date-. Reprogramming Hour/Date.
Inst. access The control panel programming has been changed.
Delinquency The zone"Inactivity Time" has expired, from when the status zone is changed.
Tel. Line Telephone line failure: call the installer. ! (1)
Table 14 List of Faults: 1) ONLY Grade 3 Control Panels; 2) Depends on the zone fault label.
