Bentel Security Academy 4 - Outputs Parameters (Addresses 100 through 111)

Add. Zone 8 parameters Data
95 Assigns partitions î
96 type î
97 balance type î
98 attributes î
99 alarm cycles u
+
Addresses no. 80 to 99 are not active on Academy4.
Outputs parameters (Addresses 100 through 111)
KEYS PARTITIONS/ATTRIBUTES SIGNALS-A- SIGNALS-B-
Partition 1 Arming delay
Alarm and
Tamper
Partition 2 Chime Fire GND
Partition 3 Entry Time
Telephone
line Trouble
Partition 4 Exit Time
Alarm and
Tamper -
restore on
bell timeout
- Alarm memory Reserved
LED ON = Normally Open
LED OFF = Normally Closed
Trouble Reserved
-
Partitions
Disarmed
Reserved
-
Partitions
Armed
Reserved
Add. Output 1 parameters Data
100 Assigns partitions; attributes î
101 signals A î
102 signals B u
Add. Output 2 parameters Data
103 Assigns partitions; attributes î
104 signals A î
105 signals B u
Add. Output 3 parameters Data
106 Assigns partitions; attributesî
107 signals A î
108 signals B u
Add. Output 4 parameters Data
109 Assigns partitions; attributes î
110 signals A î
111 signals B u
Addresses no. 106 to 111 are not active on Academy4 and Academy8.
