Chapter 3 Configuration Page 16
Gauge Min
This is the minimum scale for Gauge View
Gauge Max
This is the maximum scale for Gauge View
DC Current
Calibration
Current Calibration is factory set. If you need to alter the calibration follow the steps below:
Go to Main Menu > Setup > Input(s) > ‘Choose Current Input’ > Calibration
Step 1
See correct wiring below for shunt connections see Fig:1 :
DC Current Value
Charging Status
Label
To Next Page
