Chapter 3 Configuration Page 21
The charge efficiency needs to be adjusted according to the condition of the batteries and
temperature.
Peukerts Exponent
Peukerts exponent or ‘n’ can be calculated using the formula on the previous page.
Reset
This reset will put actual battery capacity back to a maximum state
Tank
Setup
Go to Main Menu > Setup > Input(s) > ‘Choose Tank Input’ > Settings
Note: Tank inputs are configured for use with 0-5V senders. 10-180Ω and 240-33Ω senders must
be used in conjunction with BEP 600-TLM-SIF.
Mode: Marking
Step 1
Enter the tank volume.
Step 2
There are 8 increments that need to be set. Divide the total tank volume by 8.
Example: a 200 litre tank will be measured in 25 litre increments.
Step 3
Start with an empty tank. Put the first increment of fluid calculated in step 2 into the tank. Select
’12.5%’ and ‘Enter’ to save the set point.
Tank Level
Tank Capacity
Label
