12
2. Lower the tensioner and place it in the
notch on the frame . Make sure the flat
pulley is well placed on the belt.
Place the belt guard on the snowblower
frame . Secure everything in place with three
hex bolts 1/4" x 1/2" three lock washers
1/4" and three flat washers 5/16’’
1. Install the belt on the clutch pulley groove
closest to the engine and on the
snowblower V pulley .
3. Secure the tensioner with the pin
and hair pin
