ED3000 Precision Reel/Cylinder Grinder
You are now the owner/operator of a Bernhard’s Express Dual 3000 which, if cared
for and operated correctly, will give you years of good service.
This manual will enable you to obtain the best results from your Express Dual so
please read it thoroughly before using your machine.
If you have any service or operational problems contact your distributor,
or phone our
Technical Helpline (USA only) – 1-888 474 6348
or
Bernhard and Company Ltd, England –
(+44) 1788 811600
or email
techsupport@bernhard.co.uk
use the technical support feedback form on our web site
www.expressdual.com or www.bernhard.co.uk
Identication of Pictograms 3
Safety 6
Installation 7
Identication of Tools and Equipment 9
Understanding the Machine 10
In Frame Grinding 12
Electrical Fault Finding 20
Maintenance 21
Part Lists and Exploded Diagrams 25
Wiring Diagrams 44
