Bernhard ED3000 - Lift Table

42
EXPRESS DUAL • ED3000
© Bernhard and Company Limited
LIFT TABLE
________________________________________________________________
1 Frame ...................................................................................... 1 A4138
2 Power Pack 220v ....................................................................1 A8954
Power Pack 24v.......................................................................1 A8023
Power Pack 12v.......................................................................1 A8770
3 L.H. Slider Plate ......................................................................1 A4127
4 R.H.Slider Plate.......................................................................1 A4128
5 Bearing .................................................................................... 2 A7744
6 Bearing .................................................................................... 2 A7744
7 Slider Plate Pin ........................................................................2 A4127
8 Plastic End Cap 60 x 60......................................................... 2 A6194
9 Taillift Platform.........................................................................1 A4139
10 Single Pulley............................................................................ 2 A7209
11 Double Pulley ..........................................................................2 A7204
12 Hydraulic Cylinder complete ................................................... 1 A6923
13 Chain Screw Tensioner ...........................................................2 A4119
14 Chain Bottle Tensioner............................................................ 2 A4022
15 L.H. Pulley Mounting Plate...................................................... 2 A4098
16 Hex Head Bolt M6 x 45 ........................................................... 1 A5722
17 Nyloc Nut M6...........................................................................1 A5517
18 R.H.Pulley Mounting Plate ...................................................... 1 A4099
19 Cover Plate.............................................................................. 1 A6319
20 Washer M6 .............................................................................. 2 A5320
21 Hex Head Screw M6 x 12........................................................ 2 A5718
22 Nut M6..................................................................................... 2 A5516
23 Lift Platform Extension............................................................1 A4137
24 Washer M8 .............................................................................. 2 A5321
25 Hex Head Set Screw M8 x 45 .................................................2 A5725
26 Nyloc Nut M8...........................................................................2 A5220
27 Lift Table Lowering Solenoid 220v.......................................... 1 A8943
Lift Table Lowering Solenoid 24v ............................................ 1 A8392
Lift Table Lowering Solenoid 12v ............................................ 1 A8391
28 Control Pendant 24v (not shown)............................................1 A8018
Mains Control Pendant (not shown)........................................1 A8890
29 Label for Tail Lift Pendant (not shown) ...................................1 A6552
30 Mains Tail Lift Controller (not shown)...................................... 1 A8904
Ref # Name of Part Qty. Part #
9. Parts List (Continued)
