© Bernhard and Company Limited
TRAVERSE ASSEMBLY
___________________________________________________
1 Forkdriver (only) ......................................................................1 A9512
Forkdriver c/w bushings & seals ............................................. 1 A9505
2 Shaft for Forkdriver .................................................................1 A9050
3 Brackets for Forkdriver Shaft .................................................. 2 A4049
4 Ball Bushing for Forkdriver...................................................... 2 A7706
5 Dust Seals for Forkdriver ........................................................2 A7707
6 Button Head Screw M8 x 30 ................................................... 4 A5164
7 Socket Screw M6 x 6............................................................... 2 A5156
8 Shaft for Pick up ...................................................................... 1 A9183
9 Traverse Pick Up ..................................................................... 1 A9518
10 Ball Bushing for Trav. Pick Up................................................. 2 A7702
11 Dust Seal for Trav. Pick Up ..................................................... 2 A7703
12 Hex. Head Screw M12 x 25.....................................................2 A5712
13 Washer M12 ............................................................................2 A5315
14 Engagement Screw ................................................................. 1 A6112
15 Lobed Knob M12 .....................................................................1 A6102
16 Reversing Bar.......................................................................... 1 A4111
17 Reversing Bar Stop .................................................................2 A4113
18 Cross Knob M8 x 15................................................................ 2 A6131
19 Microswitch..............................................................................1 A8111
20 Housing for Microswitch ......................................................... 1 A8113
21 Guard for Microswitch ............................................................. 1 A6382
22 Screw 2BA x 1 ”.................................................................... 2 A5404
23 Traverse Motor 60Hz...............................................................1 A6024
Traverse Motor 50Hz...............................................................1 A6022
24 Idler Sprocket ..........................................................................1 A7609
25 Oilite Bush for Sprocket ..........................................................1 A7704
26 Spindle for Idler Sprocket........................................................1 A9057
27 Drive Sprocket.........................................................................1 A7603
28 Traverse Chain ........................................................................ 1 A7406
29 Link for Traverse Chain ........................................................... 1 A7502
30 Circlip ” ................................................................................. 1 A5602
31 Hex. Nut M10...........................................................................1 A5503
32 Socket Screw ..........................................................................1
33 Hex Head Screw M6 x 18........................................................ 4 A5719
34 Washer M6 .............................................................................. 4 A5320
35 Capacitor 3uf for Traverse Motor ........................................... 1 A8148
36 Friction Spring for Reversing Bar ............................................ 1 A6746
37 Socket Screw ”Whit x ”...................................................... 1 A5101
9. Parts List (Continued)
Ref # Name of Part Qty. Part #
