EXPRESS DUAL • ED3000
© Bernhard and Company Limited
Ref # Name of Part
Qty. Part #
MAINSHAFT MOUNTING AND MAIN MOTOR DRIVE
__________________
1 Side Arm L.H........................................................................... 1 A4122
2 Side Arm R.H. .........................................................................1 A4123
3 Rear Shaft c/w circlips ............................................................1 A9108
4 Circlip.......................................................................................2 A5601
5 Main Motor 220v 60Hz............................................................ 1 A6014
Main Motor 240v 50Hz ............................................................ 1 A6015
Main Motor 3 phase................................................................. 1 A6016
6 Drive Pulley 60 Hz...................................................................1 A7202
Drive Pulley 50Hz....................................................................1 A7203
7 Taperlock Bush 1108 x 19 .......................................................1 A7301
8 Driven Pulley ...........................................................................1 A7201
9 Taperlock Bush 1610 x 1” ..................................................... 1 A7303
10 SPZ Drive Belt 60 Hz .............................................................. 1 A7103
SPZ Drive Belt 50Hz ...............................................................1 A7102
11 Drive Belt Guard...................................................................... 1 A6334
12 Mainshaft.................................................................................1 A9068
13 Grinding Stone ........................................................................ 1 A6505
14 Sleeve......................................................................................1 A9116
15 Nut ........................................................................................... 1 A9095
Sleeve and Nut assembly ....................................................... 1 A9506
16 Mainshaft Bearing ................................................................... 1 A7721
17 Oilite Bush 1” bore................................................................2 A7701
18 Plastic Washer......................................................................... 2 A6759
19 Hex.Nut M12............................................................................4 A5506
20 Washer M12 ............................................................................8 A5315
21 Hex. Head Bolt M12 x 45......................................................... 4 A5714
22 Hex. Head Bolt M8 x 25 ..........................................................4 A5216
23 Washer M8 .............................................................................. 4 A5321
24 Motor Bolt Retaining Plate ......................................................2 A4078
25 Hex. Set Screw M10 x 70 ........................................................2 A5711
26 Locknut M10 ............................................................................ 2 A5503
27 Button Head Socket Screw M5 x 10 ....................................... 2 A5129
9. Parts List
(Continued)
