Bernhard ED3000 - Multi-Fix Bracket Assembly

36
EXPRESS DUAL • ED3000
© Bernhard and Company Limited
MULTI-FIX BRACKET ASSEMBLY
_______________________________________
1 Adjustable Mtg Brkt Base L.H.................................................1 A4012
2 Adjustable Mtg Brkt ‘V’ Base ..................................................2 A4011
3 Adjustable Mtg Brkt Base R.H. ...............................................1 A4014
4 ‘L’ Upright Mounting Brkt R.H.................................................. 1 A4010
5 ‘L’ Upright Mounting Brkt L.H. .................................................1 A4009
6 Adjustable Mtg Brkt Horizontal ...............................................2 A4016
7 Mounting Brkt ‘C’ Clamp L.H. .................................................1 A4006
8 Mounting Brkt ‘C’ Clamp R.H.................................................. 1 A4007
9 ‘C’ Clamp Screw......................................................................2 A4008
10 ‘V’ Bracket Clamp Finger ........................................................ 2 A4003
11 Kip Lever M10 x 20..................................................................4 A6118
12 ‘V’ Bracket Stud M16............................................................... 2 A5401
13 Kip Lever M12 x 30.................................................................. 4 A6121
14 Slide Nut M10 .......................................................................... 2 A4180
15 Nut M16 .................................................................................. 2 A5508
16 Wing Nut M16 .......................................................................... 2 A5509
17 Cap Head Skt Screw M10 x 25 .............................................. 4 A5116
18 Washer M12 ............................................................................4 A5315
19 Washer M10 ............................................................................4 A5310
20 Base Scale ..............................................................................2 A6601
21 Button Head Skt Screw M4 x 8 ............................................... 4 A5125
22 Multix Channel (not shown)...................................................2 A4087
Ref # Name of Part Qty. Part #
9. Parts List (Continued)
