Bernhard ED3000 - Page 32

32
EXPRESS DUAL • ED3000
© Bernhard and Company Limited
REEL DRIVE
________________________________________________________________
1 Reel Drive Motor......................................................................1 A6011
2 Layshaft (Long) .......................................................................1 A9059
3 Layshaft (Short).......................................................................1 A9060
4 Layshaft Bearing .....................................................................2 A7722
5 Socket for Flexible Drive ......................................................... 2 A9121
6 Flexible Drive Shaft .................................................................1 A7404
7 Flexible Drive Bracket Base ....................................................1 A4046
8 Retaining Nut........................................................................... 1 A4110
9 ‘L’ Post Drive Hd Support Bar .................................................1 A4001
10 Flexible Drive Bracket ............................................................. 1 A4045
11 Cylinder Drive Motor Bracket ..................................................1 A4031
12 Cross Knob M8 x 15................................................................ 2 A6131
13 Ball Spring Plunger .................................................................2 A5460
14 Cap Hd Screw 5/8”Whit x 5 1/2” ............................................. 1 A5109
15 Socket Screw M6 x 12............................................................. 1 A5146
16 Diamond Dresser .................................................................... 1 A6737
17 Locknut M10 ............................................................................ 1 A5503
18 Flexible Coupling.....................................................................1 A6744
19 Grub Screw 3/8” Whit x 3/8” ...................................................2 A5106
20 Short Square Drive Shaft ........................................................1 A4134
Ref # Name of Part Qty. Part #
9. Parts List (Continued)
