Bernina Bernette Funlock b44 - Threading the Upper Looper (Blue)

20
Threading the Upper Looper (Blue)
– Thread the upper looper as indicated (1)–(8).
– Raise Presser foot to release tension discs.
1
2
3
8
6
4
5
7
1
2
2
3
3
1
2
3
8
6
4
5
7
1
2
2
3
3
CAUTION:
Be sure to turn off power switch.
– Pass thread from back to the front through the
thread guide (1).
– Thread the top cover thread guide by pulling the
thread towards the left until it slips under guide
(2). Then pull thread along the right side of
button as illustrated.
– While holding thread with fingers, pass it
between the tension discs and pull thread down
to make certain it is properly located in between
the tension discs (3).
