OPTIONAL ACCESSORIES
The following optional presser feet specially prepared
for this machine are available at extra–charge.
The snap–on type presser foot of this machine permits
easy removal and replacement.
Snap–On Type Presser Foot
• Removal
– Raise presser foot and raise needle bar to its
highest position.
– Press red colored lever (A) located on back of
clamp under the presser foot shank, raise
presser foot lever to its High Lift position and
while holding the presser foot lever in this
position, remove the presser foot plate.
• Replacement
– Place presser foot plate on stitch plate under
presser foot shank so that hinge pin (C) will fit
in slot (B) of the shank. Then lower presser foot
lever.
– If presser foot plate can not be placed under
presser foot shank easily, raise presser foot
lever to its High Lift position and while holding it
in this position, place presser foot plate under
presser foot shank. Then lower presser foot
lever.
– Raise presser foot lever and make sure the
presser foot plate is properly attached to the
presser foot shank.
PLEASE NOTE:
Do not use presser foot made for other machi-
nes. Use of such presser foot may result in inter-
ference with the needle and knife and can be
hazardous.
CAUTION:
Before lubricating your machine, disconnect
power line plug from the wall receptacle.
C
B
A
C
B
A
