Threading the Lower Looper (Red)
– Thread the lower looper as indicated (1)–(9).
– Raise Presser foot to release Tension discs.
– Pass thread from back to the front through the
thread guide (1).
– Thread the top cover thread guide by pulling the
thread towards the left until it slips under guide
(2). Then pull thread along the right side of
button as illustrated.
– Thread the looper area of the machine following
the blue color coded thread guides (4)–(8).
– Thread the hole in the upper looper from front
to back (8).
10cm
(4")
7
8
2
3
9
6
4
5
7
1
8
1
2
2
6
7
8
4
5
10cm
(4")
7
8
2
3
9
6
4
5
7
1
8
1
2
2
6
7
8
4
5
PLEASE NOTE:
Make sure thread passes behind lower looper.
Use tweezers provided in the accessory case to
aid in threading the looper.
