22
– While holding thread with finger, pass it between
the tension discs and pull thread down to make
certain it is properly located in between the
tension discs (3).
– Turn the handwheel toward you until the lower
looper extends out 5–10 mm from the stitch
plate edge.
– Thread the looper area of the machine following
the red color coded thread guides (4)–(9).
– Place the thread with the point of the tweezers
slightly from left and to the right of threading
guide (4).
– Thread the looper eye (A) from front to back.
– Pull about 4“ (10 cm) of thread.
– Position thread into V cutout (B) on threader.
– Firmly hold thread tail with left hand and pull
Threader lever (C) up into place (D).
3
9
6
4
5
7
8
5
6
7
4
C
98
D
B
A
3
3
9
6
4
5
7
8
5
6
7
4
C
98
D
B
A
3
3
9
6
4
5
7
8
5
6
7
4
C
98
D
B
A
3
PLEASE NOTE:
Use tweezers provided in the accessory case to
aid in threading the looper.
