Bestop Trektop NX - Section 5: Install Sunrider Bracket; Step 1: Place Sunrider Bracket; Step 2: Secure with Knob

Page 12
Install Sunrider Bracket
Section 5
Step 1 Step 2485.50 480.22
Hardware
Sunrider Bracket
Qty - 1 per side
485.50 Right (shown)
485.51 Left
M8 x 30mm Knob
Qty - 1 per side
Part # 480.22
Step 1 Step 2
Place the Left Sunrider Bracket over the hole where
the Front and Rear Door Surrounds join.
Secure it with the M8 x 30mm Knob. Repeat
with the Right Sunrider Bracket. Repeat on
both sides.
