Bestop Trektop NX - Section 9: Attach Side Bows to Header;Fabric Assembly; Step 1: Remove Header Screws; Step 2: Insert Side Bows

Page 16
Attach Side Bows to Header/Fabric Assembly
Section 9
Step 1
Step 2
485.47
Hardware
Side Bow
Qty - 1 per side
Part # 485.47
Step 1 Step 2
Remove the screws in the Header Assembly and
set aside to be reused.
Insert Side Bows into Header Assembly on
each side.
Pivot quick release knobs to face toward
inside of assembly.
