Bestop Trektop NX - Section 2: Install Rear Bow Brackets; Step 1: Locate Rear Sport Bar Bolt; Step 2: Mark Bracket Position

Page 8
Install Rear Bow Brackets
Section 2
Step 1 Step 2484.86
Hardware
Rear Bow Bracket
Qty - 1
Part # 484.87 - Left
Rear Bow Bracket
Qty - 1
Part # 484.86 - Right
Step 1 Step 2
Locate the rear sport bar bolt. Use a 13mm socket
and ratchet to remove the bolt and set it aside to be
reused.
Loosely install the Rear Bow Bracket with
the sport bar bolt. Mark where the bracket
contacts the sport bar cover and remove the
bracket.
