Bestop Trektop NX - Section 6: Install Front Top Arch; Step 1: Insert Front Top Arch

Page 13
Install Front Top Arch
Section 6
Step 1 Step 2483.24
Hardware
Front Top Arch
Qty - 1
Part # 483.24
Step 1 Step 2
Insert one end of the Front Top Arch in to the slot
in the middle of one of the Front Door Surrounds.
Push the other end inward to flex the bow and
insert it into the slot on the other side of the vehicle.
Remove and dispose of paper film.
