Page 15
Install Tailgate Bar Mounts
Section 8
Step 1 488.46
Hardware
Tailgate Bar Mount
Qty - 1 per side
488.46 Right (shown)
488.47 Left
Step 1
Orient the Tailgate Bar Mounts on the vehicle.
Hook the bottom of one mount under the
ledge and roll the mount toward the outside
of the vehicle until it clips into place under the
belt rail. Repeat this with both Tailgate Bar
Mounts.
