MAINTENANCE AND CHECKS

Left shaftLeft shaft

Left shaft

To replace the oil, proceed as follows:

1) Remove the front wheel

2) Remove the handlebar (see pag. 65)

3) Unloose the shaft lock the screws

4) Unscrew slider plug

5) Remove the spring and totally empty

the oil

6) Reset the spring and fill with oil

(OJ01 ) up to the level indicated in

figure

Note:Note:

Note:

For all changes, follow the instructions

given on the chart on pag. 62, using the

Iubricants recommended on pag. 47.

Check regularly and clean thoroughly

removing any dirt on dust cover and also

check the rubber seal to ensure a good

seal.

120 mm

Oil

level

Note:Note:

Note:

For screw A: torque wrench setting

7,8 : 9,1 Nm.
