MAINTENANCE AND CHECKS

REAR BRAKEREAR BRAKE

REAR BRAKE

CheckCheck

Check

To check the rear brake for wear, simply

observe the caliper from the rear, where it

is possible to see the ends of the two pads.

These pads should have at least a 2 mm

Iayer of Iining. if this Iayer is thinner than

2 mm, replace the pads immediately.

Note: Note:

Note: Observe the times given on the

chart on pag. 62 when performing the

check.

ReplacementReplacement

Replacement

To replace the pads, proceed as follows:

•Unscrew the screw A

•Make to slip the pads towards the sock

posterior (see arrow), favoring the spill-

age of the pads.

•Remove the pads and replace them

•To reassemble, proceed in the reverse

order. Apply “frenafiletti medio” to the

screw A.

If the brake disk is removed, applyIf the brake disk is removed, apply

If the brake disk is removed, apply

Loctite to the screws whenLoctite to the screws when

Loctite to the screws when

reassembling.reassembling.

reassembling.
