Beta REV 3 User Manual

43
GENERAL INFORMATION
GB
1
TECHNICAL DTECHNICAL D
TECHNICAL DTECHNICAL D
TECHNICAL D
AA
AA
A
TT
TT
T
AA
AA
A
VV
VV
V
ehicle weightehicle weight
ehicle weightehicle weight
ehicle weight
--
--
-ready to operate (unfueled) ......................................................................................... 71 (kg)
DimensionsDimensions
DimensionsDimensions
Dimensions
-total lenght .................................................................................................................. 1.985 mm
-total widht ....................................................................................................................... 830 mm
-total height .................................................................................................................. 1.120 mm
-wheelbase .................................................................................................................... 1.315 mm
-saddle height .................................................................................................................. 640 mm
-clearance from ground .................................................................................................. 300 mm
TT
TT
T
yreyre
yreyre
yre
-pressure kg/cm
2
........................................................................................... front 0,5 / rear 0,3
-dimensions ........................................................................................ front 2,75- 21” (Tube Type)
rear 4,00 - 18” (X11Tubeless)
FF
FF
F
illing capacityilling capacity
illing capacityilling capacity
illing capacity
-fuel tank ............................................................................................................................ 3 (lt)
-including reserve of ............................................................................................................ 1 (lt)
-cooling circuit liquid ...................................................................................................... 600 (cc)
-engine oil ........................................................................................................................ 550 (cc)
FF
FF
F
ront suspensionront suspension
ront suspensionront suspension
ront suspension
-hydraulic fork with 38 mm φ rods, adjustable in extension, and loading of springs.
Oil content in shafts:
-right ....................................................................................................................................... 370cc
-left........................................................................................................................................... 350cc
Rear suspensionRear suspension
Rear suspensionRear suspension
Rear suspension
-single-element hydraulic shock absorber with progressive system, adjustable in extension
and loading of spring
FF
FF
F
ront and rear brakeront and rear brake
ront and rear brakeront and rear brake
ront and rear brake
-disk-type with hydraulic control
EngineEngine
EngineEngine
Engine
-type ................................................................................................................. BETA6605 ZD3B9T
-number of cylinders ................................................................................................................ 1
-bore x stroke ...................................................................................................... 72,5x60,5 mm
-displacement (cm
3
) ................................................................................................................ 249,7
-compression ratio ................................................................................................................ 11,4:1
-liquid cooled
-electrical digital ignition by magneto flywheel alternator with variable spark advance
-kick-starter
-spark plug..................................................................................................... NGK BR7ES
FF
FF
F
uel systemuel system
uel systemuel system
uel system
-carburetor .................................................................................................. KEIHIN PWK28
-jet ........................................125 Min 50 - Max 115; 250-270 Min 48 - Max 110
-operation with unleaded gas/oil fuel mixture:
-synthetic oil.............................................................................................................................. 1,5%
(-mineral oil................................................................................................................................ 4%)

Beta REV 3 Specifications

General

Manufacturer	Beta
Model	REV 3
Fuel System	Carburetor
Starting System	Kickstart
Transmission	6-speed
Final Drive	Chain
Engine Type	Single-cylinder, two-stroke
Cooling System	Liquid cooled
Ignition	Electronic
Rear Suspension	Sachs shock absorber
Front Brake	Disc
Rear Brake	Disc
Front Suspension	Marzocchi upside-down fork
