3
ADJUSTMENTS
33
GB
HANDLEBAR ADJUSTMENT
U-BOLT POSITION ADJUSTMENT
The lower bracket 1 can be mounted on
the holes nr. 2, 3 or 4 respectively.
1
2
2
3
4
3
4
ADJUSTMENT OF GAS
CLEARANCE
The throttle control cable should always
have a 3-5 mm play. In addition, the idle
speed should not change when the han-
dlebars are fully rotated to the left or right.
Push back protective cap 1. Loosen coun-
ternut 2 and turn adjusting screw 3.
Tighten the counternut and check that the
throttle twist grip turns smoothly.
2
3
1
IDLE ADJUSTMENT
The minimum speed is controlled directly
by the electronic control unit. Any manual
adjustment is not allowed.
WARNING! Do not modify the indi-
cated screw for any reason. Modify-
ing the position of this screw may
cause abnormal response behaviour
and engine operation. Moving the
indicated screw, in terms of the war-
ranty, is considered tampering.
