4
CHECKS AND MAINTENANCE
59
GB
•Tighten the cap to the completely ex-
tended leg.
LEGS ASSEMBLY AND PARTS
Apply the legs to the vehicle and tighten
the screws to the torque indicated.
WARNING:
grease the screws before their application.
WARNING:
Tightening of the screws should be
carried out by adjusting the torque
wrench to the stability torque with
repeated tightening until stability
torque has been achieved.
Apply wheel and wheel bolt.
Apply brake caliper, disc cover and fender.
Tighten brake calliper and U-bolt to the
indicated torque, after depositing medium
resistance threadlocker.
Place the vehicle on the ground.
17Nm
12Nm
1,5Nm
35Nm
