TIGHTENING TORQUE OVERVIEW
Here below is an overview of the tightening torque of all pieces subject to adjust-
ment or maintenance:
Forecarriage
Tighteningtorque[Nm] Threadlock
Wheel pin 50
Fork foots - wheel pin 10*
Brake caliper - Fork 35 M
U-bolt fork tube protection 1,5
Steering head base - fork legs 12*
Steering head - fork legs 17*
Stem pin on steering head 20
Lower handlebar u-bolt - steering head 40 M
Upper handlebar u-bolt -
lower handlebar u-bolt
25
Rear axle
Tighteningtorque[Nm] Threadlock
Wheel pin 130
Rear shock absorber - frame 70
Rear shock absorber - rocker arm 70
Connecting rod - frame 90
Connecting rod - rocker arm 90
Rocker arm - swinging arm 90
Engine
Tighteningtorque[Nm] Threadlock
Engine oil drain plug 15
Paper oil filter plug 10
Gearbox oil drain plug 20
M Medium strength threadlock
* WARNING:
Tightening of the screws should be carried out by adjusting the torque wrench to
the stability torque with repeated tightening until stability torque has been achieved.
