GENERAL INFORMATION
9
GB
Get off the male end wrenches (8 mm) and
hexagon socket 3. With these is possible
to unscrew the screw 4.
Pull the left cover of rear fender and unhook
two rubber band 5. Now the toolkit 6 is
accessible.
To take the tool kit, remove the saddle 1
(page 76). Pull the rear side panel Pull the rear side panel 2
(page 77).
4
1
2
3
6
5
5
