Bewacom Technical manual 11
1
SW1 push button. Used to set the
password and erase the memory.
2
Connection to the telephone system.
3
Exit button. Connect terminal nos 12
and 13. Looped = door open.
4
Time control from the external time
clock. Input 1: Connect terminal nos 11
and 13. Input 2: Connect terminal nos 10
and 13. Looped input = the codes are
disabled.
5
Camera relay output.
6
Tamper switch. Normally closed when
the housing is closed.
7
Power supply in, terminal nos 1 and 2.
8
Electric locking device. Dashed line
refers to locks with failsafe function.
9
Speaker volume.
10
Microphone sensitivity.
11
Jumper for 12 or 24 V voltage suuply. If
above 20 V, set the jumper to 24 V.
