Technical data
3-1
3 Technical data
3.1 General characteristic features
• Flame scanner with integrated amplifier and flame re-
lay
• Tested by the German Technical Inspection Associa-
tion TÜV, approved by DIN DVGW and CSA
• For continuous, intermittent and 72-hours operation
• CFC 200 UV: For monitoring gas and oil-fired burn-
ers in the UV range
• CFC 200 UV1: For monitoring gas and oil-fired burn-
ers in the UV range
• CFC 200 IR: For monitoring diffusion flames in the
IR range
• CFC 200 IR3: For gas surface burner and reheat-
ings
• Adjustable sensitivity for analog output flame intensity
0(4) to 20 mA
• LED status display for flame relay and flame intensity
• No additional wiring to external flame amplifiers
• Type of protection: IP 65
