Content
i
1
General aspects 1-1
1.1
Introduction 1-1
1.2
Warning notes 1-2
1.3
Copyright protection 1-3
1.4
Disposal information 1-3
1.5
Warranty 1-4
1.6
Obligation of the operating company 1-5
1.7
Liability disclaimer 1-6
1.8
Declaration of conformity 1-7
1.9
Address of the manufacturer 1-8
2
Safety 2-1
2.1
Intended use 2-1
2.2
Requirements on persons 2-2
2.3
Safety instructions 2-3
2.4
Safety devices 2-4
2.4.1
Fundamental aspects 2-4
2.4.2
Safety devices on the compact flame controller 2-4
2.5
Safety instructions in case of maintenance and troubleshooting 2-5
2.5.1
Fundamental aspects 2-5
2.5.2
Electrical / electronic devices 2-6
2.5.3
Testing in keeping with the German Workplace Safety Ordinance (BetrSichV) 2-7
2.5.4
Safety test prior to initial operation 2-7
3
Technical data 3-1
3.1
General characteristic features 3-1
3.2
Electrical system, Optical and Mechanical Data 3-2
3.3
Weight 3-3
3.4
Dimensions 3-3
3.5
Setting elements 3-4
3.5.1
Sensitivity potentiometer 3-4
3.5.2
Select the current output 3-4
3.6
Block diagram CFC200 3-5
4
Transport, Installation and Connection 4-1
4.1
Scope of delivery 4-1
4.2
Accessories (optional) 4-1
4.3
Checking for completeness 4-1
4.4
Report any damage 4-2
4.5
Packaging 4-2
4.6
Forwarding instructions 4-2
4.7
Weight of Compact Flame Controller 4-2
4.8
Space requirement 4-3
4.9
Installation 4-4
4.9.1
Works setting of the compact flame controller 4-9
4.9.2
Adaption of the compact flame controller to the firing installation 4-10
4.10
Connection 4-11
4.10.1
Electrical connection 4-11
4.10.2
Terminal diagram 4-12
4.10.3
Handling of cable shielding KW5/KW6 4-13
4.10.4
Laying the special cable KW5/KW6 4-14
4.11
Storage 4-15
