Technical data
3-2
3.2 Electrical system, Optical and Mechanical Data
spectral sensitivity
CFC 200 UV1 (formerly 8.0)
190 bis 550 nm
CFC 200 UV (formerly 8.30)
280 bis 420 nm
CFC 200 IR (formerly 8.40)
300 bis 1050 nm
CFC 200 IR3 (formerly 8.70)
1050 bis 2700 nm
Sight view angle 2,7 °
Self monitoring fully electronic
Operating voltage 24 V DC
Current consumption approx. 200 mA
Design according to class III SELV
Ambient temperature -20 degrees to +70 degrees C
Current output
0/4…20 mA, Ra < 250 Ω
Flame relay 1 changeover contact, floating
VDE 0110, class A
max. 48 V switching voltage
max. 1 A switching current
(fused with 0.5 A)
max. 30 W switching power
Thresholds „Flame ON“ 5 (8) mA
„Flame OFF“ < 5 (8) mA
Adjustment with sensitivity potentiometer
Safety switch-off time set by factory to 1 s
Sight view connection 1“ inner thread ISO 228
Purge air connection ½“ inner thread ISO 228
Purge air volume 10 m³/h
