BIFFI ALGAS - Page 24

20
85 30 41
100 30 41
135 30 30
175 30 30
235 30 30
280 17 55
335 17 55
385 17 55
435 17 55
485 17 55
535 17 55
585 17 55
635 17 55
735 17 55
785 17 55
835 17 55
885 17 55
935 17 55
1000 17 55
1100 17 55
1200 17 55
1300 17 80
1450 17 80
MAN 604A Rev. 5
Operation and Use
Section 3: Operation and Use
Figure 16
Pneumatic cylinder size Wrench c1 (mm) Wrench c2 (mm)
Pneumatic cylinder size Wrench c1 (mm) Wrench c2 (mm)
Table 11.
Table 12.
June 2020
Installation, Operation and Maintenance Manual
