34
MAN 604A Rev. 5
Maintenance
Section 5: Maintenance
June 2020
Installation, Operation and Maintenance Manual
5.3 Lubrication of Mechanism
For normal duty the scotch yoke mechanism of the actuator is lubricated "for life". In case
of high load and high frequency of operation it may be necessary to periodically restore
lubrication: it is advisable to apply a generous coating of grease on the contact surfaces of
the yoke and bushings, on the yoke link grooves, on the sliding blocks, on the guide bar.
For this operation it is necessary to disassemble the mechanism cover. In larger actuators
the lubrication can be performed through the inspection holes of the cover after removing
the plugs.
It’s necessary restore the grease into spring cartridge (for this operation remove the plug
on end-ange of spring cartridge and restore a generous coating of grease)
The following grease is used by Bif for standard working temperature and suggested for
re-lubrication:
AGIP MU/EP/2
To be used in standard
temperature conditions:
(-30 °C/+85 °C)
NLGI consistency: 2
Worked penetration: 280 dmm
ASTM Dropping Point: 185 °C
Base oil viscosity at 40 °C: 160 mm²/s
ISO Classication: L-X-BCHB 2
DIN 51 825: KP2K - 20
Equivalent to: ESSO BEACON EP2
BP GREASE LTX2
SHELL ALVANIA GREASE R2
ARAL ARALUB HL2
CHEVRON DURALITH
GREASE EP2
CHEVRON SPHEEROL AP2
TEXACO MULTIFAK EP2
MOBILPLEX 47
PETROMIN GREASE EP2
Table 17.
AEROSHELL GREASE 7 or equivalent
To be used in low
temperature conditions:
(-60 °C/+65 °C)
Color: Buff
Physical state: Semi-solid at ambient
temperature
Odour: Slight
Density: 966 kg/m³ at 15 °C
Flash Point: >215 °C (COC)
(Based on synthetic oil)
Dropping point: 260 °C (ASTM D-566)
Product code: 001A0065
Infosafe No.: ACISO GB/eng/C
