BIGTREETECH MMB CAN V1.0 User Manual

BIGTREETECH MMB CAN V1.0 User Manual
4
Product Profile
BIGTREETECH MMB CAN V1.0 is a control board for multi-material 3D printing
system, e.g., ERCF. It simplifies wiring by communicating via USB or CAN.
Feature Highlights
 The board has BOOT and RESET buttons, allowing users to update
firmware in DFU mode via USB.
 I2C interface reserved for filament run out/clogging detection, or other DIY
functions.
 The power interface has reverse polarity protection to prevent the board
from being damaged if power cables are connected incorrectly during DIY.
 Supports CAN or USB communication, with selectable 120R terminal
resistance for CAN and reserved CAN expansion interface.
 USB port has ESD protection to prevent controller damage from
electrostatic discharge.
 Uses XT30 interface for CAN communication and board power supply,
simplifying wiring.
 Stepper motor driver supports high and low voltage selection for DIY use.
Specifications
Dimensions
125mm x 54mm
Installation Size
Refer to
BIGTREETECH MMB CAN V1.0-SIZE.pdf
Microprocessor
ARM Cortex-M0+ STM32G0B1CBT6 64MHz
Input Voltage
DC12V-DC24V 9A
Logic Voltage
DC 3.3V
Servo Interface (MOT)
Maximum Output
5V 2A, peak 2.5A
Expansion Interfaces
STP1-STP11, I2C, RGB, Sensor (infrared sensor
interface), USB, CAN
Motor Driver Support
EZ Drive (supports voltage selection)
Driver Operating Modes
STEP/DIR, UART, SPI
Stepper Motor Interfaces
M1, M2, M3, M4
USB Communication
Interface
USB Type-C
DCDC 5V Output
Maximum Current
3.6A

BIGTREETECH MMB CAN V1.0 Specifications

General

Brand	BIGTREETECH
Model	MMB CAN V1.0
Category	Computer Hardware
Language	English
