4.2.2 LAN
A Local Area Network (LAN) is a shared communication system to which many computers are
attached and is limited to the immediate area, usually the same building or floor of a building.
Router Local IP
IP Address: Enter the IP address of ADSL Router in dotted decimal notation, for example,
192.168.1.254 (factory default).
IP Subnet Mask: The default is 255.255.255.0. User can change it to other such as
255.255.255.128.
Dynamic Route: Select the RIP version from RIP-1, RIP-2B and RIP-2M.
Direction: Select the RIP direction from None, Both, In Only and Out Only.
Multicast: IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to establish
membership in a Multicast group - it is not used to carry user data. The BiPAC 5200N supports both
IGMP version 1 (IGMP-v1) and IGMP-v2. Select None to disable it
IGMP Snoop: Choose Disabled or Enabled IGMP Snoop function.
DHCP
DHCP (Dynamic Host Configuration Protocol, RFC 2131 and RFC 2132) allows individual clients to
37
