Billion BiPAC 5200N User Manual

4.3.5 ADSL
ADSL Mode: The default setting is Auto Sync-Up. This mode will automatically detect
your ADSL, ADSL2+, ADSL2, G.DMT, G.lite, and T1.413. But in some area, multimode
cannot detect the ADSL line code well. If it is the case, please adjust the ADSL line code to
G.DMT or T1.413 first. If it still fails, please try the other values such as ALCTL, ADI, etc.
ADSL Type: There are five modes “Open Annex Type and Follow DSLAM’s
Setting”, ”Annex A”, ”Annex I”, “Annex A/L”, ”Annex M” and “Annex A/I/J/L/M” that user can
select for this connection.
63

Billion BiPAC 5200N Specifications

Operating Environment

operating temperature	0 - 40 ºC
storage temperature	-20 - 70 ºC
humidity	20 - 95% non-condensing

Physical Specifications

dimensions	185mm x 123.5mm x 36mm
wireless operation rate	Up to 300Mbps
frequency range	2.4 GHz – 2.484 GHz

Power

input voltage	12V DC
input current	1A
