(“Incoming”).or Both.
IP/MAC Filter Rule Editing
IP/MAC Filter Rule Index: This is item number
Rule Type: Choose “IP” or “MAC” rules
Active: Select Yes from the drop down list box to enable IP filter rule.
Source IP Address: The source IP address or range of packets to be monitored.
Subnet Mask: It is the source IP addresses based on above source subnet IP
Source Port Number: This Port or Port Ranges defines the port allowed to be used by
the Remote/WAN to connect to the application. Default is set from range 0 ~ 65535. It is
recommended that this option be configured by an advanced user.
Destination IP Address: This is the destination subnet IP address.
Subnet Mask: It is the destination IP addresses based on above destination subnet IP
Destination Port Number: This is the Port or Port Ranges that defines the application.
Protocol: It is the packet protocol type used by the application, select either TCP or UDP
or ICMP
Rule Unmatched: Select action for the traffic unmatching current rule; Forward to leave it
pass through, and NEXT to check it by the next rule.
IP/MAC Filter Listing
#: Item number.
Active: Whether the connection is currently active.
Src Address/Mask: The source IP address or range of packets to be monitored.
Dest IP/Mask: This is the destination subnet IP address.
Src port: This Port or Port Ranges defines the port allowed to be used by the
Remote/WAN to connect to the application. Default is set from range 0 ~ 65535. It is
recommended that this option be configured by an advanced user.
Dest Port: This is the Port or Port Ranges that defines the application.
Protocol: It is the packet protocol type used by the application, select either TCP or UDP
or ICMP
Unmatched: It show this profile’s setting :Forward or NEXT
66
