BD / ED / FD (E2) 03/2019 page 44/68
Chamber size ED 23 ED 53 ED 115 ED 240 ED 400 ED 720
Electrical data
(model versions ED023-230V, ED053-230V, ED115-230V, ED240-230V, ED400-230V, ED720-230V)
IP system of protection acc. to EN 60529 20 20 20 20 20 20
Nominal
voltage
(±10 %)
at 50 Hz power frequency V 230 230 230 230 400 400
at 60 Hz power frequency V 230 230 230 230 400 400
Current type 1N~ 1N~ 1N~ 1N~ 3N~ 3N~
Nominal power kW 0.8 1.20 1.60 2.70 3.40 5.00
Chamber fuse
5 x 20 mm / 230V / middle-time-lag (M)
Amp
10
external
10
external
10
external
16
external
3 x 16
internal
3 x 16
internal
Power plug Grounded plug CEE plug 5 poles
Installation category acc. to IEC 61010-1 II II II II II II
Pollution degree acc. to IEC 61010-1 2 2 2 2 2 2
Different electrical data for ED-UL constructed for the USA and Canada (model versions ED023UL-
120V, ED053UL-120V, ED115UL-120V, ED240UL-208V, ED400UL-208V, ED720UL-208V)
Nominal voltage (±10 %)
at 60 Hz power frequency
V 115 115 115 208 208 208
Current type 1N~ 1N~ 1N~ 3N~ 3N~ 3N~
Nominal current Amp 7.0 10.5 14.0 11.2 10.6 15.6
Power plug NEMA 5-20P 5-20P 5-20P L21-20P L21-20P L21-20P
Chamber fuse
6,3 x 32 mm / 250V / super-time-lag TT
Amp
12.5
external
16
external
16
external
3 x 16
internal
3 x 16
internal
3 x 16
internal
Environment-specific data
Noise level (mean value) dB (A) < 45 < 45 < 45 < 45 < 45 < 45
Energy
consumption
at 70 °C / 158 °F
Wh/h 43 60 90 143 201 220
at 150 °C / 302 °F
Wh/h 148 210 300 447 672 750
at 300 °C / 572 °F
Wh/h 450 600 360 700 1000 1200
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of +22 °C +/- 3 °C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of +/-10. Technical data is
determined in accordance to BINDER Factory Standard Part 1:2015 following DIN 12880:2007.
All indications are average values, typical for units produced in series. We reserve the right to
change technical specifications at any time.
If the chamber is fully loaded, the specified heating up times may vary according to the load.
12.6 FD technical data
Chamber size FD 23 FD 53 FD 115 FD 240
Exterior dimensions
Width, net
mm / inch 435 / 17.13 635 / 25.00 835 / 32.87
1035 /
40.75
Height, gross (incl. feet/castors)
mm / inch 495 / 19.49 620 / 24.41 705 / 27.76 825 / 32.48
Depth
mm / inch 520 / 20.47 575 / 22.64 645 / 25.39 745 / 29.33
Depth, gross (incl. door handle and
exhaust duct)
mm / inch
625
24.61
680
26.77
750
29.53
850
33.46
Wall clearance rear (minimum)
mm / inch 100 / 3.94 100 / 3.94 100 / 3.94 100 / 3.94
Wall clearance side (minimum)
mm / inch 100 / 3.94 160 / 6.30 160 / 6.30 160 / 6.30
Exhaust duct, outer diameter
mm / inch 52 / 2.05 52 / 2.05 52 / 2.05 52 / 2.05
Doors
Number of doors 1 1 1 2
